Renting frac tanks is an excellent choice for temporary storage of water and other liquids needed for industrial purposes. These tanks are made of sturdy steel and feature a heavy-duty design, ensuring your liquids are safely contained at your location. We offer a variety of accessories to make these large tanks adaptable to your particular project requirements, especially during filter bag replacements.

Frac Tank Features:

  • Drain/Fill:
    • 4” drain at floor each end with valve
    • 3” fill elbow at roof
    • 4” flange with valve on front – flanged on inside
    • 4” flange with blind cover plate on roof
    • 2” coupling with plug on roof
    • 4” coupling with plug on roof
    • PV vent on roof
  • Manway:
    • 21” manway on front, side, rear and roof
  • Pick up:
    • Standard 5th wheel king pin
  • Access:
    • Front ladder andstairway with 36” grating walkway to roof manway, stationary and fold down handrail system (optional).

Frac Tank Specs:

  • Dimensions:
    • Length: 42′
    • Width: 8’6″
    • Height: 9’8″
  • Capacity:
    • 21,000 gallons (400bbl)
  • Floor:
    • ¼ PL, 4” V-bottom with integral formed side channels
  • Floor support:
    • 10” channel longitudinal runners with 8” channel and formed ¼ PL channel crossmembers
  • Walls:
    • ¼ PL solid welded, smooth inside, with formed channel supports outside
  • Coating:
    • Steel grit blast, 100% solids epoxy chemical resistant interior lining @ 20mil DFT, exterior coated with high solids rust inhibiting polyurethane @ 5 mil DFT. Ask for chemical compatibility.
